VS-NH02
Vicus-Vida
VS-NH02
VS-NH02 High Pressure Solar Water Heater Blend Polyols
Introduction
VS-NH02 is the pale yellow to brown yellow transparent liquid which is used special polyol as main raw
materials, with special additives to make up of blend polyols.
Features of the products are as follows
1).Low odor and environmental protection, use high activity polyol and odorless catalyst, which can reduce
stimulation to respiratory tract of body, protect our healthy effectively.
2).Good flowability during the reactivity process of blend polyols and isocyanate, the density of the forming
foam distributes uniformity.
3).Excellent dimensional stability, cohesiveness and nozzle smoothness.
4).Applies to process requirements of high pressure solar energy.
Typical Physical Index
Appearance | Pale Yellow to Brown Yellow Transparent Liquid |
Hydroxyl Value ,mgKOH/g | 300-360 |
Dynamic Viscosityat 25 ℃ , mPa.s | 300-450 |
Specific Gravity at 20 ℃ | 1.10-1.15 |
Storage Temperature , ℃ | 10-25 |
Shelf Lift | 6 months at Temperatures of 20-30°C |
Processing condition characteristics
Item | Manual Mixing | High Pressure |
Mixing Ratio (PBW) | VS-NH02: MDI =100: 100-105 | |
Material Temperature , ℃ | 20-25 | 20-25 |
Mold Temperature , ℃ | 35-45 | 35-45 |
Cream Time , s | 12-16 | 8-12 |
Gel Time , s | 75-85 | 40-60 |
Tack Free Time , s | 100-120 | 90-110 |
Free Density , kg/m3 | 27-29 | 27-28 |
The actual value varied depends on the processing conditions | ||
Foam Property
Moulding Temperature | ≥38kg/m3 | |
Closed-Cell Rate | ≥90% | |
Thermal Conductivity at 15℃ | ≤0.019 W/m.K | |
Compressive Strength（Perpendicular to The Uprising Direction） | ≥140MPa | |
Dimensional stability | 24h at -20℃ | ≤0.5% |
24h at 100℃ | ≤1.0% | |
Packing： 220kg/Net Steel Drum/IBC Tank
